Resun LP Low Noise High Pressure Air Pump

Resun LP Low Noise High Pressure Air Pump

The Resun LP Low Noise High Pressure Air Pump is a quiet, affordable electromagnetic diaphragm air pump for fish and koi ponds, aquariums and other water-aeration jobs. It suits pond keepers who want plenty of air without a noisy compressor, and it comes in two output levels to match different pond sizes.

Key Benefits

• Very quiet running thanks to electromagnetic linear diaphragm technology.
• Automatic thermal cut-out overload protection.
• Plastic body with a 1.5 m (4.9 ft) power cable.
• IPX4 rating: it should sit in a low-dust spot, but it tolerates rain and light sprinkling.
• High output for its power draw, an economical way to move a lot of air.
• Supplied with a plastic multi-outlet manifold for splitting the air to several air stones or lines.

How to Use

• Place the pump in a low-dust environment. Light rain or sprinkling is tolerated, but it should not be left in dusty conditions.
• Set the pump up above the water level, or fit a check valve in the air line so water cannot siphon back into the pump.
• Connect 4 mm (0.16") silicone air line to the manifold outlets and run it to your air stones or diffusers.
• Keep some back pressure on the unit, for example by running air stones in the water. This extends the life of the rubber diaphragms.

Suitable For

• Fish and koi pond aeration. The smaller model suits smaller fish and koi ponds, while the larger model suits the vast majority of fish and koi ponds.
• Aquariums.
• Aquaculture pond aeration.
• Commercial and industrial water aeration.
• Bubble baths.
• Larger model only: deepwater septic tank aeration, and natural swimming pond or pool aeration.

Compatibility

• The manifold outlets are designed for 4 mm (0.16") silicone air line.
• Must be installed above the water level, or fitted with a check valve.
• Run with back pressure, such as submerged air stones, to protect the diaphragms.

Specifications

• LP-20 voltage / wattage: 240V / 17W
• LP-20 maximum pressure: 0.028 MPa / 280 mbar / 2.8 m H2O
• LP-20 maximum air output: 1320 L/hr (22 litres per minute)
• LP-20 outlet diameter: 16 mm (0.63")
• LP-20 maximum water depth for placed air stones: 2.2 m (7.2 ft)
• LP-20 manifold: plastic, 6 outlets
• LP-20 dimensions: 205 mm (8.1") L x 145 mm (5.7") W x 165 mm (6.5") H
• LP-20 weight: 2.25 kg (5.0 lb); cartoned 2.65 kg (5.8 lb)
• LP-40 voltage / wattage: 240V / 35W
• LP-40 maximum pressure: 0.03 MPa / 0.3 bar / 300 mbar / 3 m H2O
• LP-40 maximum air output: 3000 L/hr (50 litres per minute)
• LP-40 outlet diameter: 18 mm (0.71")
• LP-40 maximum water depth for placed air stones: 2.8 m (9.2 ft)
• LP-40 manifold: plastic, 12 outlets
• LP-40 dimensions: 245 mm (9.6") L x 175 mm (6.9") W x 185 mm (7.3") H
• LP-40 weight: 4.25 kg (9.4 lb); cartoned 4.85 kg (10.7 lb)
• Both models: electromagnetic linear diaphragm, automatic thermal cut-out overload protection, plastic body, 1.5 m (4.9 ft) cable, IPX4 rated

Available Sizes

• LP-20 (17W, 1320 litres per hour, 280 mbar)
• LP-40 (35W, 3000 litres per hour, 300 mbar)

What's Included

• One air pump
• A plastic manifold for 4 mm (0.16") silicone air line: 6 outlets with the LP-20, 12 outlets with the LP-40

Frequently Asked Questions

Can I use this pump outdoors on a pond?
Yes, with care. It is rated IPX4, so it tolerates rain and light sprinkling, but it should still be housed in a low-dust environment.

Do I need a check valve?
The pump must either sit above the water level or be fitted with a check valve. This stops water from running back down the air line into the pump.

Why does the pump need back pressure?
Back pressure extends the life of the rubber diaphragms. Running the pump into submerged air stones provides it.

Which model suits my pond?
The LP-20 delivers up to 1320 L/hr and suits smaller fish and koi ponds. The LP-40 delivers up to 3000 L/hr and suits the vast majority of fish and koi ponds. It also suits applications such as natural swimming ponds and deepwater septic tank aeration.

How deep can I place air stones?
The maximum water depth for placed air stones is 2.2 m (7.2 ft) with the LP-20 and 2.8 m (9.2 ft) with the LP-40.

What size air line does the manifold take?
The supplied plastic manifold suits 4 mm (0.16") silicone air line. It has 6 outlets on the LP-20 and 12 outlets on the LP-40.
